Description
AVAILABLE AT: CORSICA, PA
STANDARD Features:
- NATM Certified
- Extruded Aluminum Tube Frame: Durable, Lightweight
- A-Frame Tongue for Superior Support
- 3-Year Structural Warranty
- Welded on Bridge Sides for More Strength and Safety of Cargo
- 1750 lb Capacity Bolt on Ramp
- LED Lighting
- Sealed Plug and Play Wiring Harness
- 15” Radial Tire
- Dexter 3,500 lb. 4” Drop Spring Axles
- 1,000 lb. Swivel Jack w/wheel
- 5/4”x 6″ Pro Wood Dura Color Treated Decking
- Rear, Removeable 3-position Ramp
- Spring Loaded Gate Latch
- Aluminum Through-Bolted Greaseable Hinge
- 4 Tie-Down Points (6 on tandems)
OPTIONAL Features:
- Side Loading Ramp (5′ wide)
- Bi-Fold Ramp (Rear and/or Side)
- Trailer Brakes
- Spare Tire-Mount (Weld-on or Bolt-on)
- Matching Spare Tire
- Aluminum Rim Upgrade
- Flush Mount D-rings
| SPECIFICATIONS | |
|---|---|
| Deck (Length/Width) | 144″ / 78″ |
| Overall (Length/Width) | 195″ / 102″ |
| Crossmembers | 24″ On-Center |
| Frame | 2″ x 4″ Tube |
| Decking | 5/4″ x 6″ Treated |
| Deck Height | 17″ |
| Rail Height (above deck) | 13″ |
| ATP Side Walls | Optional |
| Rear Ramp | 4′ Standard |
| Suspension | Double Eye Spring |
| Axle(s) (Qty/Rating) | (1) 3,500 lb. idler |
| Wheels | 15″ Silver Spoke |
| Tires | ST205/75R15 C Radial |
| GVWR | 2,990 lb. |
| Curb Weight | 620 lb. |
| Payload Capacity | 2,370 lb. |
| CouplerRating / Ball Size | 3,200 lb. / 2″ Ball |
| Hitch Height | 14″ |
| Power Connection | 4-Way Flat |
| Lights | LED |
| Wheel Jack | Standard |
| Safety Chains | 3,200 lb. / 24″ |
