Description
ACL Main Bearing Set for Toyota Supra 2JZ 2JZGE / 2JZGTE 3.0L – 7M8103H
7M8103H
7M8103HX
7M8103H – .25
7M8103H – .025
The unique combination of design, metallurgy and engineering come together to deliver what drivers expect from high performance Trimetal engine bearings.
Designed to withstand higher RPM conditions, ACL Race Series Connecting Main Bearings are available for many of the popular 4, 6 & 8 cylinder applications and feature:
* *High strength overlay plate* with reduced thickness for improved fatigue properties
* *Hardened steel backs* on all rod bearings to improve the support of the bearing lining and assist with bearing retention in the housing.
* *Increased crush* for improved bearing retention
* *Elimination of flash plating* on the back of the bearings to improve heat transfer through the bearings and to maximize the grip between the bearings and its housing.
* *Increased eccentricity* to compensate for bore distortion at high rpm and to assist in the formation of hydrodynamic oil films.
* *Tight consistent wall tolerances* to help you maintain consistent clearances.
* *Enlarged ID chamfers* on bearing edges where required to accommodate large fillet radius on performance crankshafts.
NOTE: Multiple sizes available. Select size before adding to cart.
“H” = Standard Size
“H-.25″ = .25mm Thicker than stock. Use this when your crank is cut .010”
“H-.025″ = .025mm Thicker than stock. Use this when you need .001” less oil clearance.
“HX” = +0.001 in extra oil clearance
